SALIENT FEATURES

l  Stepping Motor means Accurate, reliable operation

l  Direct readout of all measurement parameters

l  Auto Range Showing

l  Time Function for measurement

l  Sound alarm at under 20%Torque Liner calibration

l  Wide range power supply: 100V-240V

TECHNICAL SPECIFICATIONS:

·     Measuring Range (mPa.s)             20-2,000,00 m.pas

·    RPM                                 `0.3, 0.6, 1.5, 3,6, 12, 30, 60

No of standard spindles                #1,#2,#3,#4 is standard configuration

,(#0 is for option)

·     Measuruement                       accuracy 1.0% OF range

·     Repeatability                        + 0.5%

·     Display                             LCD

TEMPERATURE

·     RTD Monitoring                        Yes

·     Sensor Probe

·     Output                               RS 232 Interface

·     Power Supply                           AC 220V/50Hz

·     Dimension LxWxH                400 x 350 x 360

·     Weight                               9Kg
