TECHNICAL SPECIFICATIONS

l Fluoro Sensitivity    Full scale deflection obtained with 1ppm quinine in 001 N Sulphate acid (primary wavelength 360nm)

l Display  3 Digit Bright Red Seven Segment LED Display

l Excitation Range   12V,50W Tungsten Halogen Lamp

l Sensitivity Range   Adjustable in 4 ranges

l Primary Filters       Corning 5840 (360nm) and Corning 5113 (405nm) Cell mounted on holders

l Secondary Filters  Corning 4308 (465nm), Corning 3486(650nm)

l Detector        Highly sensitive wide range photodiode /cell

l Sample Test Tube     15mm (D) x 80mm (H)

l Minimum Sample  4m

l Power   230V±10%,50Hz.AC

l Weight   5 kg. (Approx.)
